Product Description
The High-capacity PP Packaging Belt One Output Two Production Line by Zhongrui is designed for high-speed production of PP packaging belts, including ultra-thin and environmentally friendly options. Featuring advanced technology and robust construction, this production line ensures high tensile strength, low elongation rates, and exceptional durability, making it suitable for a wide range of packaging applications.
Advanced Technology for High Output
Zhongrui's High-capacity PP Packaging Belt Production Line incorporates cutting-edge technology to meet the growing demands of the packaging industry. This line offers the capability to produce two belts simultaneously, enhancing production efficiency without compromising on quality. The specially designed screw facilitates optimal melting and mixing of PP materials, ensuring a consistent and reliable extrusion process.
Superior Production Features
Equipped with a stainless steel cooling water tank, the production line guarantees excellent temperature control, minimizing defects in the final product. The unique laser embossing roller creates clear and even patterns, enhancing the aesthetic appeal of the straps. Additionally, the adjustable die allows for precise thickness control, accommodating varying packaging needs.
Energy Efficiency and Sustainability
This production line is not only powerful but also environmentally friendly. It supports the use of 100% recycled materials, significantly reducing waste. The energy-efficient design consumes 40% less power compared to conventional machines, making it an economical choice for manufacturers.
Product Features
High Production Capacity: One output two design allows for increased efficiency.
Customizable Specifications: Adjustable die head ensures precise production of various strap sizes.
Durable Construction: Built with high-quality materials, including stainless steel for longevity.
Energy-Efficient: Reduces energy consumption significantly while maintaining output.
Advanced Cooling System: Ensures consistent temperature control for high-quality production.
By choosing Zhongrui's High-capacity PP Packaging Belt Production Line, you are investing in a reliable solution that maximizes production capabilities while adhering to sustainability practices. Whether for steel, construction materials, or agriculture, this line meets diverse packaging needs with ease and precision.
Product Parameters
| Item | 75/30
|
| Screw Qty. | 1 or as request |
| Straps Qty. | One out 4 straps:5mm, 8mm
One out 2 straps:12mm,15mm |
| Output/Day | 2-4.5T |
| Screw Dia. | 75/90mm |
| Screw L:D | 30:1 |
| Positioning Accuracy | 0.3mm |
| Winder Qty. | 2-6 or as request |
| Working Voltage | AC220V-380V 50/60HZ |
| Material used | Virgin Material/Recycled |
| Power usage | 26kw/h |
| Installed power | 60kw/h |
| Strap specifications | Width 5-19mm, thickness 0.3-1.2mm |
| Workshop area | Length 40m, width 5m, Height:4m |
| Product Dimensions | 32000mm(L) x 1500mm(W) x 3000mm(H) |
| Main Equipment&Qty. | 1.Feeding System 1
2. Extruder 1
3.One Out Two and Four Mould
4.High Precise Metering Pump 1
4.Stainless Steel Sink 1
5.Tracting Unit 1
6.Far Infrared Heating Oven 1
7.High Speed Stretching Unit 1
8.Tensile Embossing Equipment 2
9.Shaping Oven 1
10.Water Tank 1
11.High Speed Traction Unit 1
12.Convey Belt 1
13.Single Station Winder 4 |
| Compliance | SGS/ISO9001/CE Certification |
| Warranty | One years limited warranty with lifetime support |
| Recommendation | For the PP Strapping Production Line, we also supply the following items: |
| PET Strap Production Line | Plastic Recycling Machine |
| Semi Automatic Strapping Machine | Strapping Tools |
Qingdao Zhongrui Plastic Machinery Co., Ltd. production of PP packaging belt production line to introduce advanced technology, after painstaking research, the development of a new generation of one-machine PP packaging belt production line, the production line can produce ultra-thin packaging belt, rice packaging belt, environmental packaging belt, the production of the product pattern neat and clear, light weight, The extruding machine of a double belt packing belt production line is made of 38 chromium, molybdenum and aluminum by nitriding treatment, adopting the latest compression ratio in line with PP characteristics, the progressive screw barrel, the special hard tooth surface reducer of the plastic machine, and the high specification configuration to ensure the extrusion effect. The die head of the PP packing belt production line adopts a mechanical fine-tuning die head, and the strip forming is smooth and stable. Stainless steel cooling water tank, new big five roller traction to ensure the stable growth of product molding quality. The new winding technology overcomes the phenomenon that the product skew is large and the bend deformation is serious after the winding of the previous equipment, and the winding is smooth. Embossing roller embossing, pattern clear, uniform, beautiful product appearance grade. Precise dosing and mixing of raw materials. Automatic cycle of preheating and drying. Plasticizing uniform extrusion stability, accurate temperature control. Metering pumps guarantee a continuous and stable product. Large traction product drawing device and insulated oven. Large capacity stainless steel sink, liquid level automatic control. Specially designed screw extruder. It can use 100% recycled material strong vacuum system, which can avoid the dehumidification and drying of raw materials. Energy consumption is 40% lower than raw materials. The company can provide process formulations and turnkey engineering.
After-sales service
1. Demand analysis: Fully understand customer needs and analyze according to the actual situation
2. Professional program: professional engineer design, customer review and confirm the program
3. Order production: sign the contract, arrange production, return the delivery date, and ensure the completion of production quality and quantity
4. After-sales service: free equipment installation, commissioning, training personnel, regular visits
