▍Features of PVC glazed tile production line
A PVC glazed tile extrusion production line is a manufacturing setup designed to produce PVC tiles with a glazed surface finish. The process involves extruding PVC resin mixed with additives and pigments through a die to form continuous sheets. These sheets are then cooled, cut to size, and undergo glazing treatment to provide them with a smooth, glossy surface. The production line often incorporates precision control, automation, and quality checks to ensure consistent output of high-quality glazed PVC tiles suitable for various flooring and wall covering applications.
▍The composition of PVC glazed tile production line
| No | Name | Number |
| 1 | Screw loader for SJZ80/156 | 1set |
| 2 | SJZ80/156 Conical twin screw extruder | 1set |
| 3 | drying hopper for SJ50/30 | 1set |
| 4 | Vacuum loader for SJ50/30 | 1set |
| 5 | SJ50/30 single screw extruder | 1set |
| 6 | Extrusion Mould and Distributor (T-die) | 1set |
| 7 | DistributorForming machine | 1set |
| 8 | Embossing roller Trimming device | 1set |
| 9 | Embossing roller | 1set |
| 10 | Cutter | 1set |
| 11 | Stacker | 1set |
▍Raw material & Final product of ROOF TILE MAKING MACHINE:
| Raw material & formulation | PVC resin, Caco3, lubricant,stabilizing agent, pigment, anti-ultraviolet agent,Pigment etc |
| Central height: | 1000mm |
| Max. Haul-off speed: | 3m/min |
| Operation direction | From right to left (face to the operation panel) |
| Machine color | Standard color: RAL7016 (Anthracite grey) ;
RAL9002 (Grey white) |
| Description final product & Output capacity | Singlelayers PVC Roofing tile;
Width:500-1500mm,Thickness: 1.2~3.0mm;
Wave distance:180mm; Wave height:30mm;
Output:300-400kg/h(Depending on CaCO3 proportion) |
▍About us
PVC is the main raw material of plastic tiles. As a plastic tile manufacturer, we also have good relations and close cooperation with many construction projects. Based on the rich knowledge in the PVC field and the many needs of existing customers, the tiles we produce can better meet the needs of use and can replace traditional asbestos tiles, iron tiles, steel tiles, and wood. PVC tiles can be used for a longer time, are resistant to corrosion, and are not easy to leak. They are widely used in many countries in South America and Southeast Asia. We are also happy to bring high-quality products to more countries and regions!
